Description
Thermal mass flow meter from SUTO Itec. Used advantageously to monitor the flow of compressed air. The compact S415 flow meter comes in a inline version for dimensions between DN08 to DN25, it is equipped with a 4..20mA signal and Pulse output, Modbus RTU is available as an option.
Technical specification
| MODELL | S415 (Eco) |
| MEASURING RANGE | 50…3500 l/min |
| CONNECTION | Inline DN08 – DN25 |
| TEMPERATURE | 0…50°C |
| ACCURACY | ± 3% läst värde |
| UTSIGNAL | 4..20mA, Puls, RS-485 |
| PROTECTION CLASS | CE, RoHS, IP54 |
